Description

Electrical properties                    TRX UHF.6.1

MMDS TRANSCEIVER	Downstream
RF Input	620-638 MHz
Gain	27 dB
Gain flatness	+ - 1.6 dB, full band
Noise figure	4 dB type., 4.8 dB max
Inband spurious	-70 dBm

Electrical specification
RF Output	560-590 MHz
IF Output	12-24 MHz
Gain	27 dB
Gain flatness	+ - 1.5 dB, full band
P1 output dB	32 dBm

General
Phase noise	-98 dBc/Hz@10kHz
LO leakage at RF/IF ports	-50 dBm
LO Frequency stabilty	+ - 14 kHz (-30°to 60°C)
IF Connector (Rx out/Tx in)	F 75 Ω
DC Consumption (12-20 Vdc)	7.5W
Operating temperature	-30°to 60°C
